Three Bond 2206C - 1K Epoxidharz - 1 kg Dose

Three Bond 2206C – 1K epoxy resin overview

The Three Bond 2206C is a 1K epoxy resin that features a solvent-free formulation and a fast curing capability. In electronics manufacturing it offers low outgassing and shrinkage as well as excellent electrical and chemical properties.

This white epoxy resin system belongs to the category epoxy adhesive and is typically supplied in a 1 kg can. The viscosity at 25 °C is approx. 75 Pa s, the density approx. 1,20 g cm3.

Electronics applications

For electronic components and enclosure seals, the epoxy resin Three Bond 2206C with low outgassing, shrinkage and excellent electrical properties provides a reliable bonding and sealing solution.

Dimensions and specifications

• Color: White
• Main component: Epoxy resin
• Viscosity (25 °C): approx. 75 Pa s
• Density (25 °C): approx. 1,20 g cm3
• Shear strength: 9 MPa
• Shore hardness: D 96
• Thermal conductivity: 4,2 W/m·K
• Thermal conductivity: 4,2 W/m·K
• Curing time (100 °C): approx. 40 minutes
• Storage life: approx. 3 months

Key features and benefits

The solvent-free in-use formulation with 1K enables easy processing. The high hardness (Shore D 96) ensures durable connections, while low outgassing and shrinkage increase the reliability of sensitive electronic applications.

• Reduced outgassing and shrinkage improve long-term stability
• White color design facilitates visual inspection and coatings
• Good electrical properties even under temperature cycling

Application tips

Curing occurs at 100 °C in about 40 minutes. The product is supplied in a 1 kg can and should be stored in a cool and dry place to maintain a storage life of 3 months. Cleaning before bonding with suitable cleaners, surface degreasing and, if applicable, preheating support uniform curing.
