Three Bond 3302B - Flexibler Leitkleber (Urethan-Basis) - 200 g Dose

Three Bond 3302B – A20173 Overview

Three Bond 3302B is a flexible conductive adhesive based on urethane in a 200 g can. As a 1K adhesive, it offers high flexibility and excellent adhesion on various materials. The color is silver, providing a visible bond that is well-suited for conductive connections. The Main component is urethane + silver.

The adhesive is processable from approx. 17 °C and is characterized by its moderate to low viscosity, allowing it to spread well without dripping.

Technical Data

• Part number: A20173
• Brand: Three Bond
• Main component: urethane + silver
• Color: Silver
• Viscosity 25 °C: 15 Pa·s
• Density 25 °C: 2.73 g/cm³
• Volume resistance: 3×10??
• Curing: 60°C 3 h

Properties & Benefits

With high flexibility, the bonding remains stable even under deformations, which is especially important for circuit-board seals or flexible components. The 1K formulation simplifies processing, as no mixing ratio is required.

• High flexibility and good adhesion
• One-component system simplifies the assembly process
• Silver content supports conductive connections

Application & Practice

Apply the adhesive evenly to the surface to be prepared and avoid air bubbles. Work at ambient temperatures from approx. 17 °C to ensure uniform curing.

Material & Composition

Composition: urethane adhesive with metallic silver content; ideal for conductive bonding connections.

Key Features

One-component glaze enables easy handling, and the silver component supports conductive connections. The solution is suitable for applications requiring a flexible, conductive adhesive bond.
